Beskrivelse
Pin deskription:
1. VDD 3.3 ~ 5.5V DC
2. GND, ground, negative pole of power
3. SDA serial data, two-way port
4. SCL serial clock, input port
Technical Parameters:
1. Humidity measurement range: 0 ~ 100% RH
2. Humidity measurement accuracy: ± 2% RH
3. Temperature measurement range: -40 ~ 125 ℃
4. Temperature measurement accuracy: ± 0.2 ℃
5. Working voltage: 3.3 ~ 5VDC
6.I2C interface output
Application:
HVAC, dehumidifiers, agriculture, cold chain storage, testing and testing equipment, consumer products, automobiles, automatic control, data loggers, weather stations, home appliances, humidity regulators, medical, and other related humidity detection and control.
